2024 Haulmore ‘Super Duty’ Tri Axle Side Tipper
New build For sale Side Tippers

2024 Haulmore ‘Super Duty’ Tri Axle Side Tipper

Haulmore · 2024 · Price on application

'Super Duty' tri-axle side tipper with 4 mm Hardox body, 21 m³

Source build sheet — as published

Haulmore “SUPER DUTY” Tri Axle Side Tipping Trailer Body constructed from Hardox Grade 450 High tensile Swedish Steel High Capacity Tipping Rams 150mm Diameter Full length door (piano) hinge Safety lock-on door opening Double Sheer brackets on door hinge Four body floor support beams Dual Tyre carrier Heavy duty landing legs

Get a quote

FOOTAGESee it work

PRECISION VIEWERWalk the floor it's built on
  • Design rating 47,000 kg
  • Tare weight 9,100 kg
  • Suspension 9 leaf 2.7m spread
  • Axle configuration tri-axle

LIVE SCAN Haulmore works · Hazelmere, WA

TELEMETRY SOURCE 2024 Haulmore ‘Super Duty’ Tri Axle Side Tipper build sheet

TELEMETRYFull specification

Mass & Ratings

Design rating47,000 kg
Tare weight9,100 kg

Dimensions

Overall width2900mm overall
Height of sides1000mm
Body length (inside)9000mm inside

Running Gear

TyresThirteen (13) only
Stud count10 stud
Suspension9 leaf 2.7m spread
Leaf count9 leaf
Suspension spread2.7m spread
Axle configurationtri-axle
Axle count3

Braking & Electrical

Brake systemDrum brake
ABS/EBSEBS
ElectricalMulti-voltage
LightingLED

Deck & Body

Body material4mm Hardox GR450 Swedish high tensile plate

Capacity

Body volume21 cubic metres

Securing & Accessories

King pin90mm
Hitch typering feeder

BUILD FEATURESEngineered in

  • Grade 450 High tensile Swedish Steel
  • High Capacity Tipping Rams 150mm Diameter
  • Dual Tyre carrier

DEPLOYMENTBuilt for

Bulk material haulageMiningAggregate cartage
